Avian CR3 DBX

About CR3 DBX
Extra wide rim designed for Gravel.

Feature

Wide Rim
24mm internal width, 30mm external, compatible with wide tyre better.

Offcenter
Offcenter rim for 35mm to ensure similar spoke tension of drive and non drive side.

T800 Rim
With 50% T800 reinforced to reduce weight and meet the strength need of gravel.

Mega-Structure
No external hole design. The continuous structure make the rim stronger and stiffer. Rim tape is not needed and thus saves another 50 grams in use.

Pillar Wing20
Aero superlight stainless spoke.

Sapim Secure Lock
Secure Lock nipple prevents the self rotation of spoke in long use. Less likely to loosen and ran-out.

Ratchet System
Stable and easy to maintain by changing ratchet ring inside.

Specification
Rim: Avian CR3 DBX
Brake Type: Disc Brake
Tyre Type: Clincher/Tubeless
Axle Type: Thru Axle
Disc Type: Center Lock
Width: 30MM
Height: 35/45MM
Weight: 1270G/1370G
Spoke: Pillar Wing20
Nipple: Sapim Secure Lock
Hub: Avian R300
Holes: 24/24
Warranty: 2 Years(Rim&Hub)
Comes with: Spacer
